功能特点:性能好,高效区宽广;静压效率高,运行平稳,安装使用方便。
局扇型号 |
电机功率(kw) |
风量(m³/s) |
全压(Pa) |
最小风筒直径(mm) |
送风距离(m) |
外形尺寸(mm) |
||
D |
L |
H |
||||||
JK58-1№3 |
1.5 |
0.9-1.4 |
928-575 |
300 |
80 |
390 |
486 |
230 |
JK58-1№3.5 |
3 |
1.5-2.4 |
1263-752 |
350 |
150 |
450 |
562 |
260 |
JK58-1№4 |
5.5 |
2.2-3.5 |
1648-1020 |
400 |
200 |
520 |
649 |
290 |
JK58-1№4.5 |
11 |
3.1-5.0 |
2093-1295 |
450 |
300 |
585 |
728 |
320 |
JK58-2№4 |
11 |
2.2-3.5 |
2923-1811 |
400 |
400 |
520 |
877 |
290 |
JK55-2№4.5 |
11 |
3.0-5.2 |
2276-1811 |
450 |
300 |
543 |
704 |
275 |
JK55-1№5 |
11 |
4.2-6.6 |
1726-1324 |
450 |
200 |
600 |
535 |
400 |
JK56-1№3.15 |
2.2 |
1.4-2.1 |
853-588 |
300 |
80 |
374 |
634 |
193 |
JK56-1№4 |
4 |
0.1-3.4 |
1275-981 |
400 |
150 |
477 |
682 |
240 |
JK67-1№4.5 |
7.5 |
2.6-4.2 |
2256-1177 |
400 |
250 |
540 |
760 |
270 |
JK67-2№4.5 |
11 |
2.8-4.3 |
3237-1471 |
400 |
400 |
540 |
860 |
270 |
BJK67-1№5.25 |
28 |
4.0-6.3 |
3776-2648 |
500 |
600 |
620 |
1364 |
310 |
JK40-1№5.5 |
5.5 |
4.3-5.1 |
633-475 |
550 |
120 |
720 |
3800 |
337 |
JK40-1№6.5 |
11 |
7.1-8.4 |
884-663 |
650 |
140 |
742 |
3800 |
396 |
JK40-1№7 |
15 |
8.8-10.5 |
1025-769 |
700 |
140 |
795 |
4100 |
425 |
JK40-1№7.5 |
22 |
10.9-12.9 |
1177-883 |
750 |
150 |
824 |
4100 |
455 |
JK40-1№8 |
30 |
13.2-15.6 |
1339-1005 |
800 |
150 |
848 |
4350 |
485 |
DJK50-№5.5 |
2×5.5 |
4.8-5.8 |
1182-515 |
550 |
180 |
948 |
3800 |
337 |
DJK50-№6.5 |
2×11 |
7.9-9.5 |
1651-719 |
650 |
200 |
1120 |
3800 |
396 |
DJK50-№7 |
2×15 |
9.9-11.9 |
1915-834 |
700 |
200 |
1207 |
4100 |
425 |
DJK50-№7.5 |
2×22 |
12.2-14.6 |
2198-957 |
750 |
220 |
1293 |
4100 |
455 |
DJK50-№8 |
2×30 |
14.8-17.8 |
2501-1089 |
800 |
220 |
1340 |
4350 |
485 |
